Special
Options |
|
Onboard
Adaptec Dual channel SCSI controler
Intel 10/100Mbit LAN controler
Dual channel PCI sloten |
|
CPU |
|
Support Dual Slot2 for IntelŪ PentiumŪ 2, III Xeon Processor
Supports 400MHz~800Mhz / 4096Kb/cache
|
Chipset |
|
Intel
80440GX Server chipset
Integrated I/O APIC |
FSB |
|
Supports 100MHz FSB |
Main
Memory |
|
Support 4 memory banks 168-pin
unbuffered DIMM.
Support a maximum memory size of 2GB.
Support ECC (1-bit Error Code Correct) function.
Support 3.3V SDRAM DIMM.
Pinouts support 4 banks up to 2GB DRAMs (512Mb DRAM
technology)
|
Slots |
|
1,
2x AGP 66Mhz 3,3volt
6, 33MHz (3,3/5-volt) PCI slots. *
1, 16-bit ISA slots. * |
On-Board
IDE |
|
Dual-channel
master mode
Up to four Enhanced IDE devices
Support for ATA-33 compliant IDE and ATAPI compliant
devices ** |
VGA |
|
non |
On-Board
Peripherals |
|
On-Board Peripherals include:
-- 1 Floppy port supports 2 FDD with 360K, 720K, 1.2M,
1.44M and
2.88Mbytes.
-- 2 Serial ports (COM A + COM B)
-- 1 Parallel port supports SPP/EPP/ECP mode
-- 4 USB ports
-- 1 IR connector for HPSIR/ASK
-- 10/100 Intel LAN controler |
BIOS |
|
AMI BIOS on
4Mb Flash ROM
Supports APM v1.2 and ACPI v1.0
User settings for hardware monitoring
Auto-configuration of IDE hard drive types
Multiple boot options
DMI 2.0 compliant |
Dimension |
|
Extended
ATX
footprint
One 20-pin ATX power connector
Stacked parallel (one), serial (two)
Stacked USB (two) ports
Stacked keyboard and mouse ports |
Mounting |
|
10 mounting holes.
|
|
|
