 Special
Features |
| |
Soft
Menu II ™
|
| Special
Options |
| |
Onboard
Highpoint HP366
Ultra DMA ATA66 Raid Controler
Supports high performance
66Mbytes/sec Dual Channel
Mastering IDE
|
|
| CPU |
| |
Support
Socket PP-PGA for Intel® Celeron™ Processor
|
| Chipset |
| |
Intel®
440BX (66/100MHz) AGPset
Ultra DMA66 IDE controller supports Four Ultra DMA66
devices
Supports Ultra DMA/33 IDE protocol
Supports Advanced Configuration and Power Management
Interface (ACPI)
Supports AGP 1X/2X (Sideband) 3.3V device |
| FSB |
| |
Supports
66 to 133MHz FSB adjustments in 1MHz increments |
| Main
Memory |
| |
Three
168-pin DIMM sockets support SDRAM module
Supports up to 768MB MAX. (8, 16, 32, 64, 128,256MB SDRAM)
ECC support |
| Slots |
| |
One
AGP (Accelerated Graphics Port) slot.
AGP specification compliant
Five 32-bit Master PCI Bus slots.
Supports 3.3V/5V PCI bus Interface.
Two E-ISA 16/32 Bit slots. |
| On-Board
IDE |
| |
An
IDE controller on the Intel Bx440® chipset provides IDE
HDD / CD-ROM with
PIO, Bus Master and Ultra DMA 33/66
operation modes.
Can connect up to four IDE devices. |
| Audio |
| |
No
onboard sound |
| On-Board
Peripherals |
| |
Two
channels of bus Master IDE Ports supporting up to four
Ultra DMA 33/66 devices
HPT366 Raid Controler for Two Chan. Bus Master IDE Ultra
DMA 33/66 devices
PS/2 Keyboard and PS/2 Mouse connectors
One Floppy Port (up to 2.88MB)
One Parallet Port (EPP/ECP)
Two Serial Ports
Two USB Connectors
Built-in IrDA TX/RX header |
| BIOS |
| |
CPU
SOFT MENUTM II eliminates the need for jumpers or DIP
switches needed to set CPU parameters
Award Plug and Play BIOS supports APM, DMI and ACPI
Write-Protect Anti-Virus function by AWARD BIOS
Year 2000 Compliant |
| Dimension |
| |
305x240mm
ATX Form Factor |
| Mounting |
| |
9
mounting holes. |
|
|
